IMASM03 infi90 Circuit Board
Technical Specifications:
- IMASM03
- Infi90
- Printed Circuit Board
- Turbine Control Systems
- Analog Master Module
- ABB
- Bailey
The Analog Master Module (IMAMM03) enables the INFI 90 Process Management System to accept up to 64 high level, thermocouple, millivolt or resistive temperature device analog signals from a process. An IMAMM03 requires an Analog Slave Module (IMASM01/02/03/04) to condition and interface pro- cess signals. Each Analog Slave Module (ASM) provides a dif- ferent input capability. A configuration made up of function codes in Analog Master Module (AMM) memory determines the operations an AMM performs on its inputs.
